How to Install 200A Loadbreak Elbows for Cable Accessories
By:Admin
Loadbreak elbows are designed to provide a safe and easy way to connect underground power cables to transformers, switchgear, and other equipment. They are most commonly used in medium-voltage applications, such as distribution networks and industrial installations.
When selecting a loadbreak elbow, it's important to choose one that's rated for the voltage and amperage of your application. For a 15kv/24kv 200a cable, you'll need a loadbreak elbow rated for at least 15kv and 200a.
Once you've selected the right loadbreak elbow, installation is relatively straightforward. Here's a step-by-step guide to installing a 200A loadbreak elbow:
Step 1: Prepare the cable
First, you'll need to prepare the cable by stripping back the insulation to expose the conductor. Make sure the conductor is clean and free of any dirt or debris.
Step 2: Install the elbow onto the cable
Next, slide the loadbreak elbow onto the end of the cable. Make sure the elbow is fully seated and there is no exposed conductor.
Step 3: Crimp the elbow
Use a crimping tool to crimp the loadbreak elbow to the cable. Make sure the crimp is tight and secure.
Step 4: Install the connector onto the equipment
Slide the other end of the loadbreak elbow into the connector on the equipment. Make sure the connector is fully seated and there is no exposed conductor.
Step 5: Test the installation
Finally, test the installation by performing a dielectric test to ensure there are no leaks or other faults. A dielectric test involves applying a high voltage to the cable and checking for any current leakage.
By following these steps, you can install a 200A loadbreak elbow for your 15kv/24kv cable with ease. It's important to note that if you're not confident in your ability to install the elbow yourself, you should consult a qualified electrician or technician.
In conclusion, loadbreak elbows are an essential cable accessory for connecting underground power cables to equipment in medium-voltage applications. Make sure you choose the right loadbreak elbow for your application, and follow the proper installation procedures to ensure a safe and reliable connection.
